Industrial Chemical & Slurry Pumps
High-efficiency single-stage centrifugal process pumps manufactured to ISO 2858 and API 610. Engineered with enclosed or semi-open impellers, heavy wear-resistant casing alloys, and cartridge mechanical seals for highly corrosive chemical liquids and abrasive mineral slurries.
Design Criteria & Manufacturing Specifications
Manufactured strictly to international engineering codes with 100% factory pressure testing, full EN 10204 3.1 / 3.2 material traceability, and accredited third-party witness support.
| Engineering Parameter | Applicable Codes, Standards & Design Criteria |
|---|---|
| Design Standard | ISO 2858, API 610, ISO 5199 |
| Wet-End Metallurgy | SS304, SS316, 2205 Duplex, Hastelloy C, High Chrome Alloy |
| Factory Testing SOP | 100% Performance Hydrostatic & Hydraulic Curve Verification to ISO 9906 |
Industrial Heavy-Duty Pumps Standard & Engineered Models
TSV manufactures an engineered lineup of Industrial Heavy-Duty Pumps configurations for global oil & gas transmission pipelines, refinery manifolds, power plants, and severe industrial processes. Each unit undergoes 100% hydrostatic and pneumatic factory acceptance testing before dispatch.
Single-Stage End Suction Heavy Process Centrifugal Pump
Heavy-duty back pull-out design allows complete rotating assembly removal for maintenance without disturbing pipeline suction/discharge flanges.
High-Pressure Horizontal Multi-Stage Boiler Feed Water Pump
Ring-section segmented casing with multiple impellers arranged in series, engineered for high head boiler feed and mine dewatering.
Heavy-Duty Mining Slurry & Mineral Processing Solids Pump
Thick wear-resistant high chrome alloy (27% Cr) casing and closed impeller engineered to pump abrasive tailings, mill discharge, and dense mineral slurries.
Double Suction Axially Split Case High-Flow Waterworks Pump
Axially split casing allows upper half removal for instant inspection. Double suction impeller balances hydraulic axial thrust for vibration-free longevity.
Self-Priming Non-Clogging Trash & Sewage Effluent Pump
Rapid self-priming suction lift up to 7.6 meters with large two-vane open impeller that passes spherical solids up to 76 mm without clogging.
Chemical Process Cantilever Sump Submerged Pump
Vertical cantilever shaft design with no submerged bearings or mechanical seals in the fluid sump, completely immune to dry run damage.
Stainless Steel Magnetic Drive Sealless Chemical Leak-Free Pump
Hermetically sealed containment shell driven by rare-earth neodymium magnets eliminates shaft seals entirely, guaranteeing zero hazardous leaks.
Vertical Turbine Multi-Stage Deep Well & Firewater Pump
Multi-stage bowl assembly submerged below fluid level eliminates priming concerns for offshore seawater lifting and NFPA 20 industrial fire protection.
Heavy Submersible Wastewater Drainage & Sludge Pump
Hermetically sealed submersible motor with thermal overload sensors and double mechanical silicon carbide seals for deep municipal lift stations.
Inline Vertical Booster Circulation Pump for Commercial HVAC
Suction and discharge ports located in the same horizontal centerline allow installation directly into straight piping like a valve, saving floor space.
High-Viscosity Sanitary Rotary Lobe Metering Pump
Precision non-contacting bi-wing or tri-lobe rotors gently pump viscous pastes, polymers, resins, and shear-sensitive food purees without degradation.
API 610 Heavy Petrochemical Refinery Process Hydrocarbon Pump
Centerline-supported single-stage overhung process pump built strictly to API 610 12th Edition for high-temperature explosive hydrocarbon services.
100% Hydrostatic Acceptance
Every valve is pressure-tested per API 598 / API 6D Rate A with zero allowable bubble leakage prior to factory crating.
EN 10204 3.1 Certified
Certified Mill Test Reports (MTR) with optical emission spectrometer chemical composition and mechanical impact values.
Global OXY Approved Supplier
Audited and approved on the global master vendor list (#24) of Occidental Petroleum for severe upstream duties.
Explore All 4 Industrial Process Pump Configurations
1:1 aligned with TSV factory catalog. Centrifugal, multistage, and chemical slurry transport pumps manufactured to international API 610 and ISO 2858 standards.
ISO 2858 Centrifugal Chemical Pump
Back pull-out end-suction chemical process pump for corrosive petrochemical liquids.
ISO 2858 · ISO 5199 View Chemical Process Pump →API 610 Heavy Duty Process Pump
Centerline-mounted OH2 refinery pump built for continuous high-temperature hydrocarbon service.
API 610 OH2 View API 610 Process Pump →Multistage High Pressure Boiler Feed Pump
Segmental ring section high head pump for power plant boiler feedwater circuits.
High Head BB4 View Multistage Boiler Feed Pump →Heavy Duty Slurry & Tailings Pump
Severe-duty abrasive slurry transport pump with high-chrome white iron liners for mining tails.
Cr27 Mining Slurry View Heavy Duty Slurry Pump →Request Engineering Submittal & Commercial Quotation
Connect directly with our Yongjia engineering technical sales team. Receive technical engineering datasheets, CAD dimensional GA drawings, and quotation within 24 hours.
