Forged Steel Gate Valve
Heavy-duty compact forged gate valves manufactured from high-integrity forged alloy steel billets. Designed to API 602 and ASME B16.34 for high-pressure power plant steam drains, chemical injection, and sour hydrocarbon utilities with outside screw and yoke (OS&Y) rising stems.
Design Criteria & Manufacturing Specifications
Manufactured strictly to international engineering codes with 100% factory pressure testing, full EN 10204 3.1 / 3.2 material traceability, and accredited third-party witness support.
| Engineering Parameter | Applicable Codes, Standards & Design Criteria |
|---|---|
| Manufacturing Standard | API 602, BS 5352, ASME B16.34 |
| Pressure-Temperature Rating | ASME B16.34 Standard Class & Limited Class 800/1500/2500 |
| Forged Material Grades | ASTM A105N, A182 F316/F316L, A182 F11, F22, F51 Duplex |
| Wedge Structure | Solid forged wedge with precision ground guide ribs |
| Stem Design | Single-piece forged T-head stem with integral backseat shoulder |
| Packing System | Die-formed flexible graphite with braided carbon anti-extrusion rings |
Forged Steel Gate Valve Standard & Engineered Models
TSV manufactures an engineered lineup of Forged Steel Gate Valve configurations for global oil & gas transmission pipelines, refinery manifolds, power plants, and severe industrial processes. Each unit undergoes 100% hydrostatic and pneumatic factory acceptance testing before dispatch.
API 602 Bolted Bonnet Forged Steel Gate Valve
Compact forged carbon and stainless body with outside screw and yoke (OS&Y), spiral wound gasket, and hardened 13Cr/Stellite wedge for high pressure auxiliary lines.
Welded Bonnet Fully Sealed Forged Gate Valve
Hermetically seal-welded body-to-bonnet joint engineered for hazardous, toxic fluids, lethal gas lines, and high-vibration power piping.
Integral Flanged Forged Steel Gate Valve
One-piece forged body with integral flanges eliminating welded neck weaknesses, designed for offshore skid piping and severe thermal cycling.
High-Integrity Forged Body Metallurgy & Pressure-Temperature Endurance
Dense ASTM A105 / F316 forged grain structure eliminates porosity risks for severe high-pressure refinery utility manifolds.
100% Hydrostatic Acceptance
Every valve is pressure-tested per API 598 / API 6D Rate A with zero allowable bubble leakage prior to factory crating.
EN 10204 3.1 Certified
Certified Mill Test Reports (MTR) with optical emission spectrometer chemical composition and mechanical impact values.
Global OXY Approved Supplier
Audited and approved on the global master vendor list (#24) of Occidental Petroleum for severe upstream duties.
Explore All 4 Gate Valve Sub-Categories
1:1 aligned with TSV factory catalog. Navigate to specialized casting, forged steel, slurry knife gate, or power station pressure-seal configurations.
Casting Gate Valve
API 600 heavy-wall bolted bonnet cast steel (WCB, LCC, WC6) flexible wedge gate for refinery manifolds.
API 600 Heavy Wall View Casting Gate Valve →Forged Steel Gate Valve
API 602 compact forged alloy (A105, F316, F11) for severe high-pressure auxiliary vents, drains, and skids.
Current Series View Page Top ↑Knife Gate Valve
MSS SP-81 beveled stainless blade shearing through abrasive slurry, mineral tailings, and pulp lines.
Slurry & Mining View Knife Gate Valve →Self Sealing Gate Valve
Pressure-seal flexible graphite ring tightening under supercritical steam line pressures for power plants.
